Product introduction





So, if you buy a UV printer for own using:

Focus Inc. Alpha-Jet X flatbed uv printer with the newest digital inkjet printing technology offers users direct-printing capabilities onto a virtually limitless choice of three-dimensional media. In addition to supplying technology for product customization, We offer a range of small and large UV printer devices. These are machines for customizing and creating unique graphics products. Capitalizing on its peerless heritage in compact UV LED direct-to-object print technology, the plus reaffirms Focus's market dominance in this rapidly developing sector. Geared to on-demand printing of the very highest quality at industrial production levels of output, Focus Alpha-Jet X UV flatbed printer utilizes state-of-the-art technology to deliver a powerful and reliable digital alternative to traditional screen print operations.



A Smart Machine for Customizing Hundreds of items

Using the newest LED-UV curing technology, the Alpha-Jet is a low-heat, water-cool-running machine thatcombines with vibrant UV inks to print on the following materials:








Choose a Right Machine to Suit Your Budget and Your Business

FOCUS INKJET ALPHA-JET A2 SIZE UV PRINTER

Print Technology:  Micro Piezo Inkjet

Print Head:  3pcs EPSON F1080(XP600)

Head Channel:  18 channels

Head number:  3-head: White+Color+Varnish

UV system:  100-Degree adjustable

Cooling system: Water cooling

Temperature adjust:  Auto on/off. 25-35℃

UV wavelength:  395-405nm

Head protection:  Intelligent anti-scratch

Print speed:  175s/A2 size(1440*720dpi)

Print model:  Unidirection/Bidirection

Print resolution:  720*720dpi-720*3080dpi

Print type: One pass/Single/Copies

White layer:  Bottom/Top/Middle

Rip software:  FocusRIPV9.07

Image type:  Tiff, Jpeg, Png, Psd, Pdf

Repeat precision:  0.04mm

Head cleaning:  Auto flushing+Keep wet

Max. print size:  40*60cm

Print media:  Hard/Flexible/Bottle/ Tshirt

Media thickness adjust:  Software auto detection

Max. print thickness:  20cm

Ink type:  UV ink

Ink system:  Refill ink tank system

Ink process system: Auto shaking + circulation

Ink level:  Auto detection+Auto alarm

Color model:   8-color(CMYK+LC+LM+White+Varnish)

Tank volume:  500ml refillable

Color Rendition:  ICC profile+Curve

Position type:  Laser marking

Print table: Vacuum adsorption

Table treatment:  Teflon coating

Print model: 3D. Wave. Rand. Eclosion

Motion config:  Servo motor

Control interface:  Control panel+Software

Drive config:  3Pcs Linear rails+Dual Ballscrew

System require: WINXP/WIN7/WIN10 32/64bit

Working environment:  18-25℃, 50% Humidity

Working power: 120W

Electric supply:   110V/220V

Interface: USB2.0/3.0/TCPIP

Gross weight/Net weight:  230KG/150KG

Packing size: 113cm*132cm*93.5cm

Machine size:  98cm*121.5cm*67.8cm





Advantages:

1)CMYK+LC+LM+W+Varnish 8 color ink type
2)Compatible with Epson XP600 print head
3)Max. 60cm*40cm A2 printing size
4)With 3 high-power Taiwan Delta bvacuum suction fans
5)With Hiwin brand linear rail and ball screw , no noise , high speed , high resolution
6)Adopting American GMC luxury car standard insulation anti-interference wiring
7)Automatically ink wipe , maintenance system , prevent scratching and avoid printing head clog in idle time
8)Ink level sensor with light and alarm
9)Magnetic shaking setting ink the ink tank which can twirling in the bottle to avoid precipitation of white ink
10)High-sensing touch screen control button
11)Automatic detecting exactly height sensor, avoiding print head scratch
12)Stainless steel body of printer , no worry about the oxidation as ink drip on it
13)Every cable was clearly marked which is convenient for customer learning and operating
14)Stainless steel body of printer , no worry about the oxidation as ink drip on it
15)Complete acrylic cover , you couldn't find any screw or connection line on surface
etc. latest research and development results!



The UV Printing Process

UV printers use ultraviolet LED lights to dry or cure ink during the printing process. Attached to the print carriage is a UV light source that follows the print head. The LED light spectrum reacts with photo-initiators in the ink to instantly dry it so that it immediately adheres to the substrate.

With instant curing, UV printers can create photorealistic graphics on a variety of materials including items like plastic, glass and metal.

Some of the major benefits that attract businesses to UV printers are:

Environmental Safety

Unlike solvent inks, true UV inks release little to no volatile organic compounds (VOCs) which makes this printing process eco-friendly.

Faster Production Speeds

Inks cure instantly with UV printing, so there’s no downtime before finishing. The process also requires less labor and enables you to get more done in a shorter period of time than with other printing techniques.

Lower Costs

There are cost savings with UV printing because there’s often no need to use additional materials in finishing or mounting and additional protection with laminates may not be needed at all. By printing directly to the substrate, you end up using less materials, which can save you time and labor.



Absolute great samples printed

Application of China Manufactory Alpha Functional Printer DX10/DX11 Digital Printing Machine

Glass, plastic, metal, leather, acrylic, wood, ceramic, PVC, ABS, stone, cardboard, paper, cylinder bottles, balls, pens, phone cases, id cards, bags, boxes, photo album, oil paintings, slipper etc.
