Product introduction
This customized large format flatbed printer is designed for high-precision and high-efficiency printing needs. It is suitable for a variety of materials and provides excellent image quality and stable printing performance. The use of advanced inkjet technology can achieve high-definition and high-color reproduction printing effects so that each work presents a delicate and vivid visual impact.
The sturdy flatbed structure ensures that the material is stable during the printing process. It is suitable for a variety of flat materials such as glass, wood, metal, plastic, acrylic, leather, etc., meeting the needs of multiple fields such as advertising display, decoration customization, and industrial product identification. The combination of high-precision linear guides and intelligent control systems makes the printing operation more stable, effectively reduces errors, and ensures the consistency of finished product quality.
This printer supports large-format printing, one-time molding, and no splicing, and improves production efficiency. It is particularly suitable for large-size billboards, background walls, packaging panels, and other applications. The high-speed printing mode can increase production capacity while ensuring image quality to meet the needs of large-volume orders. At the same time, the equipment is equipped with environmentally friendly UV ink, which dries immediately after printing. It is not only weather-resistant but also adapts to indoor and outdoor use environments to ensure long-term non-fading and non-peeling.
Easy to operate, the intelligent control interface supports multiple file formats, has strong compatibility, and users can easily adjust parameters to achieve personalized customization. Whether you are a professional manufacturer or a personalized customization merchant, this large format flatbed printer will be your ideal choice to improve production efficiency and print quality.
SPECIFICATION
|
Focus Inc. Nebula-42F Specifications |
||
| Printing method | Piezo ink-jet technology | |
| Print head | Standard cofiguration | 2pcs*EPS F1080 Piezo print head |
| Number of nozzles | 2160 staggered, 180 x 12 rows (180 x 6 rows per each head) | |
| Jetting frequency | 16kHz max. | |
| Drop volume | 3.5～21pl (Variable data single drop & multi drop) | |
| Print resolution (dots per inch) | 360*1080dpi, 360*2160dpi,720*2160dpi; Uni-direction/Bi-dirction | |
| Print Head mainten technology | Auto keep wet cap station system & Clean flashing during printing and idle | |
| Media type | Roll feed media | Film, paper, leather etc with thickness less than 3mm |
| Media | Maximum printing width | 420mm Width X, Roll feed Y |
| Film type | DTF film | Professional Release liner DTF film |
| Transfer media | Garment transfer | Cotton, Nylon, Linen, Polyester, Chemical fiber, Leather etc. |
| Film Feeding | Automatic Release | Automatic tenssion release roller |
| Film Take up | Automatic Take up | Automatic detect electronic take up Roller |
| Film vacuum system | Automatic adsorption | Automatic adsorption aluminum vacuum table |
| Film size | Roll type | 400mm*100meter/Roll 、 310mm*100meter/Roll |
| Ink | Type | Aqueous DTF pigment ink |
| Color | KCMY LC LM+W | |
| Ink tank capacity | 220ml per each color; 500ml for white ink tank | |
| Ink process unit | White ink Stirring | Automatic white ink stirring system |
| White ink circulation | Automatic white ink circulation system | |
| Powder type | Hot melt powder | Grossus, Medium, Fines |
| Powder dusting | Automatic detect | Automatic detect & Speed adjustable |
| Powder recycle | Optional add-on | Automatic electric recycle belt, optional add-on |
| Powder melt baking | Hot melt | Far infrared rays baking @ Speed adjustable |
| Dimensions | Machine size |
Printer: 34.5(W) × 23.6(D) × 16.9(H) in. (876× 600× 431mm)
Powder process system: 27.5(W) × 57.5(D) ×19.6(H) in. (700× 1,461× 500mm)
All in one: 34.8(W) × 58.7(D) ×34.3(H) in. (884× 1,491× 873mm) |
| Packing size | 39.3(W) × 63.4(D) ×41.5(H) in. (998 × 1611 × 1053mm) | |
| Weight | Net weight | 473 lb (215 kg) for All |
| Gross weight | 649 lb (295 kg) for All | |
| Environment | Temperature | 59 to 86 °F (15 to 30 °C) |
| Humidity | 40 to 80 % | |
| Working Power | Printer 200W, Powder process system 1100W | |
| Included items | Enthernet cable, cleaning kit, USB Flash of software etc. | |
| Connectivity | Enthernet cable | |
| Power requirements | 8A Single-phase 220 V, 50HZ | |
| Acoustic noise level | 75 dB (A) or less | |
|
Software System Requirements |
||
| Print control | System | Windows® 7/10 (64 bit) Recommend |
| (Bundled) | CPU | Intel® Core™ i5, 2.5 GHz or more |
| RAM | 8 GB or more | |
| Video card and monitor | A resolution of 1,152 × 854 with 16 bit color or higher | |
| HDD | Install space 1 GB or more | |
| Working space 100 GB | ||
