Product introduction
The newest desktop DTF printer produced by Focus Technology is an innovative printing device designed for small-batch production and personalized customization. It uses advanced inkjet printing technology to print high-precision patterns directly on special film materials, and transfer patterns to a variety of materials such as cotton, polyester, blends, etc. through thermal transfer. This printer supports multiple color printing, including bright white ink, to present more delicate image details and adapt to complex design needs. In addition, its fully automated design integrates printing, powder spraying, and drying in one, which is easy and efficient to operate.
Product Advantages
This DTF printer has high precision, high efficiency, and diverse material compatibility. The printing effect is clear and smooth, with high color reproduction, especially in complex designs and gradient effects. Compared with traditional processes, it does not require plate making, significantly shortens the production cycle,e and reduces costs. Its unique environmentally friendly ink is not only water-resistant and washable, but also non-toxic and odorless, making it very suitable for products such as clothing and home textiles. In addition, the equipment is compact and has low energy consumption, which is suitable for small and medium-sized studios and personalized customization businesses, helping companies achieve high-quality production at low cost.
Application fields
The newest Desktop DTF printers are widely used in fields such as clothing customization, home decoration, advertising gifts, and creative design. It is particularly suitable for pattern transfer on T-shirts, canvas bags, shoes hats, etc., providing brands with flexible solutions for personalized customization and small-batch production. For entrepreneurs and small businesses, this device provides a cost-effective production tool to help achieve rapid transformation from creativity to products, while meeting customers' demand for diversified, high-quality customized products.
SPECIFICATION
| Focus Inc. STARFIRE-62U UV DTF Printer With Laminator All-in-One Specifications | ||
| Printing method | Piezo ink-jet technology | |
| Print head | Standard cofiguration | 3/4pcs*F1080/DX11/i3200 U1 Piezo print head |
| Number of nozzles | F1080: 3240 staggered, 180 x 18 rows (180 x 6 rows per each head) | |
| i3200 U1: 9600 staggered, 400 x24 rows (400 x 8 rows per each head) | ||
| Jetting frequency | 21.6~43.2kHz | |
| Drop volume | 3.5-12.5pl (Variable data single drop & multi drop) 2~4 Grayscale | |
| Print resolution (dots per inch) | F1080 Head: 720*1200dpi; 720*1800dpi,720*2400dpi; | |
| i3200 U1 Head: 720*720dpi; 720*1080dpi,720*1440dpi; | ||
| Print Head mainten technology | Auto keep wet cap station system & Clean flashing during printing and idle | |
| Laminating | Laminator Type | Automatic eletronic Laminating after printing |
| Laminator Roller motion | Laminator roller Electronic up down motion control under 25mm distance | |
| Lamimating temperature | 0~100℃ Adjustable | |
| Media type | Roll feed media | Roll type AB Film, Golden &Silver film, paper, Canvas, leather etc with thickness less than 3mm |
| Media | Maximum printing width | 600mm Width X, Roll feed Y no limit |
| Transfer media | Garment transfer | Mug, Cups, Glass, Metal, Acylic, Ceramic, Leather etc. |
| Film Feeding | Automatic Release | Automatic tenssion release roller |
| Film Take up | Automatic Take up | Automatic detect electronic take up Roller for Film C and Film after Laminated |
| Film vacuum system | Automatic adsorption | Automatic adsorption aluminum vacuum table |
| Film size | Roll type | 600mm*100meter/Roll |
| Ink | Type | UV dtf type ink series |
| Color | F1080 Head: KCMY LC LM+White+Varnish+*(Glue optional) | |
| i3200 U1 Head: KCMY + White+Varnish+*(Glue optional) | ||
| Ink tank capacity | 500ml per each color | |
| Ink process unit | White ink Stirring | Automatic white ink stirring system |
| White ink circulation | Automatic white ink circulation system | |
| Dimensions | Machine size | Printer: 70.9(W) × 39.3(D) × 58.2(H) in. (1800 × 997 × 1477mm) |
| Packing size | Printer packing: 77.2(W) × 52.0(D) ×36.6(H) in. (1960 × 1320 × 930mm) | |
| Weight | Net weight | 605 lb (275 kg) |
| Gross weight | 869 lb (395 kg) | |
| Working Environment | Temperature | 59 to 86 °F (15 to 30 °C) |
| Humidity | 40 to 80 % | |
| Working Power | 450W | |
| Included items | Enthernet cable, cleaning kit, USB Flash of software etc. | |
| Connectivity | Enthernet cable | |
| Power requirements | 10A Single-phase 220 V, 50HZ | |
| Software System Requirements | ||
| Print control | System | Windows® 7/10 (64 bit) Recommend |
| (Bundled) | CPU | Intel® Core™ i5, 2.5 GHz or more |
| RAM | 8 GB or more | |
| Video card and monitor | A resolution of 1,152 × 854 with 16 bit color or higher | |
| HDD | Install space 1 GB or more | |
| Working space 100 GB | ||
